Call for price
The S 1132 Binary Gradient HPLC Pump is suitable for a wide range of applications ranging from standard reversed phase HPLC up to biochromatography applications with high-salt containing-, or corrosive buffers.
Description
The Sykam S 1132 pump is part of the S 600 routine series of HPLC instruments but can just as easy be used as a stand-alone instrument. Both the analytical version (0.001 – 10 ml/min), the micro version (0.001 – 4 ml/min) and the semi-preparative version (0.1 – 40 ml/min) are available as stainless steel and PEEK pumpheads. With the optional build-in Vacuum Degasser and Active Piston Backwash the S 1132 is suitable for a wide range of applications ranging from standard reversed phase HPLC up to biochromatography applications with high-salt containing-, or corrosive buffers.
With a small footprint of only 396 x 165 x 478 mm (HxWxD) the S 1132 only takes up little bench-space. Combined with an attractive price level these pump is aimed to be an ideal choice for a wide variety of laboratory situations.
Additional information
| Dimensions | 47,8 × 16,5 × 39,6 cm |
|---|---|
| Solvent delivery method | Dual piston in series with two checkvalves |
| Pressure-flow property | 0.001 – 10.000 ml/min (analytical), 0.001 – 4.000 ml/min (micro), 0.1 – 40.000 ml/min (semi-preparative) |
| Operational pressure | (0 – 6000 psi), 0 – 40 MPa |
| Pressure feedback | Microprocessor controlled |
| Pulsation compensation | Microprocessor controlled |
| Gradient mixer | Built-in active variable volume (10 – 500 µl) |
| Pumpheads | Stainless Steel with passive piston back-seal flushing, PEEK with passive piston back-seal flushing |
| Active piston back-seal flushing | Optional |
| Built-in vacuum degasser | Optional |
